Waversa Systems WSlim LITE 2.0 Integrated Amplifier Hub

£1,850.00 £1,541.67
SKU
WSlim LITE Amplifier Hub
Free UK Delivery
24 Months
New
48 Hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

The Waversa Systems WSlim LITE 2.0 Integrated Amplifier Hub is a compact yet powerful audio solution that combines versatility and performance. With 70W per channel, DLNA streaming, DAC capabilities, Airplay, Bluetooth Apt-X, and Roon Ready status, it offers a comprehensive suite of features in a sleek, MacBook Pro-sized chassis.

Waversa Systems WSlim LITE 2.0 Integrated Amplifier Hub



The Waversa Systems WSlim LITE 2.0 Integrated Amplifier Hub is a compact yet powerful audio solution that combines versatility and performance. With 70W per channel, DLNA streaming, DAC capabilities, Airplay, Bluetooth Apt-X, and Roon Ready status, it offers a comprehensive suite of features in a sleek, MacBook Pro-sized chassis.

Utilising advanced technology like PPBTL modules for low-impedance output and WAP/WAP-X processors for optimised sound quality, the WSlim LITE delivers impressive audio performance. Its slim form factor, coupled with high-quality aluminium construction, ensures both durability and enhanced audio fidelity by minimising external noise and vibration.

Multiple digital inputs including Coaxial, Optical, and USB, along with an FM tuner, offer versatile connectivity options. Pairing with the WSlim DS expands connectivity further, adding balanced/unbalanced analog inputs, HDMI ARC, and MM/MC Phono inputs.

The WSlim LITE is also compatible with various network streaming options like DLNA, Roon, Bluetooth, and AirPlay, providing flexibility in audio streaming. With its Spotify Connect integration, accessing a vast library of music becomes effortless.



Features

  • Completely new design with on-board Waversa isolator technology
  • Slim form factor all-in-one amplifier
  • DLNA, Roon Ready, WNDR, AirPlay, USB, Coaxial, Optical, FM, Bluetooth
  • USB Host port for extension
  • Full digital circuit construction
  • PPBTL 80W / channel at DC 24V



PPBTL (Parallel Bridge Tied Load)

Waversa has thoroughly examined every aspect of digital technology, as well as amplification circuits. The WSlim LITE utilises PPBTL (Parallel Bridge Tied Load) modules, which synchronise multiple amplifiers to create a very low impedance output. This enables the WSlim LITE to drive even demanding conventional speaker systems with its compact size.



Unibody Housing

All Waversa products are built with high-quality aluminium chassis skilfully produced by an expensive CNC process. The chassis features individual segments for each module, providing protection from external noise and harmful vibration, thereby maximising audio performance.



Multiple I/Os

The WSlim LITE offers a variety of digital inputs including Coaxial, Optical, and USB, making it versatile for different audio sources. It also includes an in-built FM tuner for added convenience. To further expand the connectivity options, you can pair the WSlim LITE with the WSlim DS, which provides balanced and unbalanced analogue inputs, HDMI ARC support, MM and MC Phono inputs for connecting a turntable, and a high-output headphone jack.



Compatible with Network Play

The WSlim LITE 2.0 offers a wide range of network streaming options, including DLNA, Roon, Bluetooth, and AirPlay, providing versatile connectivity for your audio streaming needs. Additionally, it features Spotify Connect built-in, allowing you to easily access and enjoy the vast library of music available on Spotify.



Main Features

  • 2 Channel Streaming Amplifier
  • Roon Ready
  • DLNA Media Server
  • Airplay
  • Bluetooth – Apt-X
  • Wifi (Ethernet dongle required)
  • FM Tuner (Includes Aerial)



Exclusive Technologies

  • WAP – Waversa System Processor 24bit 1.5 MHz
  • WAP-X – Waversa System Processor Extension On/Off
  • WNDR – Waversa Network Direct Rendering
  • Dynamic Range Enhancement Levels 1-5



Physical characteristics

  • Chassis: Aluminium
  • Colour: Silver
  • Inputs: Ethernet (with Native DSD), USB-B, Coaxial, Toslink, Bluetooth
  • Outputs: 2 x 5 Way Binding Posts
  • I/O: USB-A, Wifi (with dongle), FM Aerial
  • Dimensions: W300 x D190 x H20mm
  • Weight: 4 kg / 8.8 lbs.
  • Power supply: 24V Adapter 90-120V AC / 180-240 VAC @ 50Hz



Supported audio / video formats

  • COAX: up to 24/192KHz
  • USB/NET: PCM 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz
  • DSD64, DSD128, DSD256 Up to 384kHz
  • ROON: FLAC, WAV, DSF, DFF, AIFF, ALAC, AAC, MQA
  • DLNA Renderer: WAV, AIFF, OGG, FLAC up to 24 bits / 192 kHz • FM – 88.0kHz – 108.0kHz



Technical Specifications

  • Linux 4.0x with 1GHz ARM Cortex A7 Processor
  • Ultra Low Power Universal Serial Bus Audio Class 2.0
  • High Precision Clock Dual MEMS 44.1/48
  • Speaker output Std: PPBTL 80w/ch 10Hz – 20kHz (+0.1/-0.5dB)
  • Speaker output Upgraded Power Supply: PPBTL 120w/ch 20kHz (+0.1/-0.5dB)



About Waversa Systems

Waversa Systems, founded by Collin Shin, aims to bring the natural sound of analogue tubes to digital replay using emerging technologies. Shin, a music enthusiast and tube lover, assembled a skilled team with experience from top South Korean companies to develop digital replay systems with 21st-century technology. Over a decade of painstaking research and development, the team has created proprietary technologies to address challenges in digital replay. With newly patented isolator devices miniaturised to fit on circuit boards, Waversa Systems has achieved its design goals, ready to share these developments with fellow music enthusiasts.



Physical characteristics

  • Chassis: Aluminium
  • Colour: Silver
  • Inputs: Ethernet (with Native DSD), USB-B, Coaxial, Toslink, Bluetooth
  • Outputs: 2 x 5 Way Binding Posts
  • I/O: USB-A, Wifi (with dongle), FM Aerial
  • Dimensions: W300 x D190 x H20mm
  • Weight: 4 kg / 8.8 lbs.
  • Power supply: 24V Adapter 90-120V AC / 180-240 VAC @ 50Hz



Supported audio / video formats

  • COAX: up to 24/192KHz
  • USB/NET: PCM 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz
  • DSD64, DSD128, DSD256 Up to 384kHz
  • ROON: FLAC, WAV, DSF, DFF, AIFF, ALAC, AAC, MQA
  • DLNA Renderer: WAV, AIFF, OGG, FLAC up to 24 bits / 192 kHz • FM – 88.0kHz – 108.0kHz



Technical Specifications

  • Linux 4.0x with 1GHz ARM Cortex A7 Processor
  • Ultra Low Power Universal Serial Bus Audio Class 2.0
  • High Precision Clock Dual MEMS 44.1/48
  • Speaker output Std: PPBTL 80w/ch 10Hz – 20kHz (+0.1/-0.5dB)
  • Speaker output Upgraded Power Supply: PPBTL 120w/ch 20kHz (+0.1/-0.5dB)
