QED X-Tube XT-400 Jumper Cables (1 Pair)
£37.00 £30.83
SKU
QED XT400 Jumpers
Lifetime
New
24 hours
Request Price MatchQED's multi award winning XT400 Speaker cable, utilising X-Tube™ Technology
Related Products
QED X-Tube XT-400 Jumper Cables (1 Pair)
QED's multi award winning XT400 Speaker cable, utilising X-Tube™ Technology Silver-plated oxygen-free copper tubular conductor geometry.
For use in the finest hi-fi and home theatre systems. This design delivers a massive cross-sectional area using X-TubeTM technology to eliminate the skin effect whilst maintaining a user friendly “figure of 8” geometry. This is QED’s ultimate affordable upgrade for high end systems.
Silver Plated 99.999% Oxygen Free Copper Conductors
Provides a low frequency path for the audio signal and delivers stunning high frequency detail
 |
X-Tube™ TechnologyAt low frequencies both X-Tube™ and conventional stranded/solid core speaker cables convey signals in a linear way. However, at high frequencies, X-TubeTM retains a near-linear signal transfer, whereas the conventional cables fail to conduct uniformly across the entire conductor area. In standard speaker cables at high frequencies current flow is highest at the periphery with rapidly deteriorating current density towards the centre of the conductor. The effect of this is to reduce the actual cross sectional area of the cable at 15kHz to less than 75% of that at low frequencies. This results in higher distortion and compromises the performance of the cable. X-TubeTM with polycore technology exhibits much lower self-inductance and is therefore less affected by this problem. The polycore technology reduces loop inductance to levels only achievable using more costly and difficult to terminate cables. The result is more high frequency detail, less distortion and greater performance. |
Specification :
- QED XT400 Jumper Cables (1 Pair) - i.e for one speaker
- These are 20cm long jumper cables made using QED XT400 speaker cable and terminated with QED's high-quality AIRLOC plugs. Ideal for bi-wirable speakers
- Can be used to connect the bass frequency binding posts to the high frequency binding posts of your speakers
- Wire gauge - 12 AWG
- Jacket Outer Diameter - 6.00mm
- Cross-sectional area - 4.00mm²
- Loop resistance - 0.008 Ω/m
- Capacitance - 43pF/m
- Inductance - 0.50 µH/m
- Dissipation factor - 0.0400
- Recommended for all high end installations
- QED Lifetime Guarantee
Termination
This cable is professionally terminated by Futureshop's expert engineers using QED's superb 24 Carat gold plated AIRLOC termination plugs.
AIRLOC is QED's specialised loudspeaker termination method and offers the very best termination with QED speaker cables. This is a solder-free, airtight fusion between the cable and plug offering optimum signal transfer, excellent signal quality and perfect long-term performance.
QED’s AIRLOC FORTE metal banana and spade plugs deliver a superior performance over many plugs offered by rival manufacturers for the following reasons. Firstly, the plug is crimped around the conductors under high pressure using a special tool supplied by QED. No soldering is used and as a result the conductors are in contact with the plug 360 degrees which maximises the surface area contact. Furthermore, the banana plug itself is in contact with the binding post again at 360 degrees. The net effect of this is it maximises the signal transfer from the plug into your equipment and hence a superior performance. When bare wire is used not all the conductors are in contact with the binding post and as a result some loss occurs.
Unfortunately the metal barrels for the AIRLOC spades were discontinued in 2012 however we still use genuine QED’s AIRLOC spade plugs with genuine QED heat shrinks over the spade plugs. This ensures every QED speaker cable comes fully terminated with the best of QED's engineering.
How to Order
From the dropdown menus' above, simply select the length of cable, the type of plugs required at the ‘Amplifier end’ and ‘Speaker end’, the amount of burn-in time required and click on the 'Add to Basket' button to add the item to your basket. Your cable will be dispatched as soon as it has been made by Future Shop's or the manufacturer’s engineers and has completed the specified burn-in process (if any), subject to Future Shop’s Terms & Conditions and stock availability. Please note, this cable is pre-bunrt in for 96 hours.
About QED Cables
QED is an award winning British company with over 40 years of experience in the audio-visual connectivity industry.
In 1973 Bob Abraham and Ian Vine founded QED Audio Products and changed the way people think about hi-fi cables. By the time QED 79 strand speaker cable was launched in 1978, it wasn’t looked upon as ‘just another speaker cable’ but was instead regarded as a serious hi-fi component, making a fundamental change in the way people thought about cables.
QED's reputation for innovation and technical excellence is known throughout the world. The latest computer-aided design techniques allow their research and development team to keep pace with technological advances and deliver products that achieve the highest levels of performance and reliability. This is why QED products are recommended by so many of the world’s leading hi-fi and home theatre equipment manufacturers.
QED offer a range of connectivity products spanning from both consumer and installation cables, wireless products and switching devices to satisfy every audio visual need.
QED is Europe's number one award winning connectivity brand and has won more prestigious cable awards from ‘What Hi-Fi? Sound & Vision’ magazine than any other brand (Awards 1981–2013).
Specification :
- QED XT400 Jumper Cables (1 Pair) - i.e for one speaker
- These are 20cm long jumper cables made using QED XT400 speaker cable and terminated with QED's high-quality AIRLOC plugs. Ideal for bi-wirable speakers
- Can be used to connect the bass frequency binding posts to the high frequency binding posts of your speakers
- Wire gauge - 12 AWG
- Jacket Outer Diameter - 6.00mm
- Cross-sectional area - 4.00mm²
- Loop resistance - 0.008 Ω/m
- Capacitance - 43pF/m
- Inductance - 0.50 µH/m
- Dissipation factor - 0.0400
- Recommended for all high end installations
- QED Lifetime Guarantee
