Kordz PRO SlimCat Cat 6 network cable - 305m Drum

As low as £247.97 £206.64
SKU
PRO-SC6
Lifetime
New
24 hours
what's this?

Please select the desired colour.

what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

Part of the multi-award-winning Kordz PRO SlimCat™ Network Cable System, the PRO SlimCat™ Network Cable is the industry-leading, highly flexible network cable designed for high density installations.

Kordz PRO SlimCat Cat 6 network cable - 305m Unterminated Drum (U/UTP, LSZH Dca, UL CM)



The Kordz PRO SlimCat Network Cable System is the perfect solution for high-density installations. The slim 4.0mm diameter cat6 U/UTP cable makes it easy to install, and it can deliver IEEE802.3bt PoE++ at 100W and 1Gbps network connectivity up to 50 metres. Fully compatible with PoE++ at 100W, together with its small cable footprint, PRO SlimCat™ network cable is ideal for easy retrofit of devices such as Wi-Fi access points and IP CCTV cameras to existing projects. Equally the cable system comes into its own when non-destructive, discrete cable running techniques are required for use in historic buildings or other challenging retrofit installs. Pair it with Kordz PRO SlimCat RJ45 Crimp Connectors and Keystone RJ45 Sockets, and terminate with the Kordz ONE Series Crimping Tool to create a complete Kordz ecosystem that ensures maximum ‘Connectivity Assured’. Get the best in network cable solutions with the Kordz PRO SlimCat Network Cable System.



Features

  • 305 metres/1000 feet per box, custom lengths unavailable at the moment
  • Black, Blue or White colour
  • CE Pro Top New Technology Award
  • Sound & Video Contractor’s Best of Show
  • Delivers ANSI/TIA-568.2-D Cat6 permanent link performance up to 50m, ideal for small and medium size installations
  • Space-saving U/UTP design, enabling reliable wired networks to the places other systems can’t reach
  • Reducing bundle sizes by almost half (cross-sectional area)
  • IEEE802.3bt 100W PoE++ capable
  • Simultaneous UL444 CM and CPR Dca fire rating for full compliance with US and EU safety requirements
  • Conveniently packaged in a Reel-in-Box delivery system that’s easy to identify in a van or on site
  • AS/NZS S008:2010 compliant
  • RoHS compliant
  • Kordz Lifetime Warranty



Low Smoke Zero Halogen (LSZH)

Uses materials to aid human safety in the event of fire. Low smoke emission aids visibility and breathability during evacuation. Zero halogens are released when the cable is subjected to high heat sources and combustion, preventing the formation of toxic and corrosive gases. This is mostly used in marine applications and throughout Europe.





Specification

CONSTRUCTION

  • Conductor: 28AWG solid OFC 0.338 +0/-0.02mm
  • Insulation: Polyethylene, 0.61±0.1 mm
  • Twisting: 4 Twisted pairs of conductors, not bonded
  • Twisted Pair Colour Code: 1: white / blue 2: white-orange / orange 3: white / green 4: white-brown / brown
  • Shielding: Unshielded (U/UTP)
  • Jacket Material: FRLSZH composite
  • Outer Diameter: 4.0 ± 0.5 mm

MECHANICAL

  • Minimum Bend Radius: Without load ≥ 16.0 mm; with load ≥ 32.0 mm
  • Temperature Range: During operation -20 °C to 60°C; During installation 0°C to 50°C

ELECTRICAL

  • DC Resistance: Max. 23.6 Ω/100 m at 20°C
  • Resistance Unbalance: Max. 4% at 20°C
  • Insulation Resistance (500V): Min. 5000 MΩ/km at 20°C
  • Mutual Capacitance: Max. 5.6 nf/100 m at 1 kHz
  • Capacitance Unbalance (Pair to ground): Max. 330 pf/100 m at 1 kHz
  • Nominal Velocity of Propagation: Nom. 67%
  • Test Voltage (DC, 1min): 1 kV / 1 min
  • Cat 6 - 1000Mbps / 1 Gbps (Max Transmission Speed at 100m) - >250 MHz (Max Bandwidth)

DIMENSIONS

  • 330mm x 265mm x 340mm / 13.0in x 10.4in x 13.4in



About The Kordz Company

Kordz is an esteemed Australian company established in 2003 to cater to the unique requirements of the custom and commercial AV installation community. With a strong focus on delivering reliable high-definition connectivity solutions, Kordz has grown into a highly regarded brand with numerous awards.

As an active member of the HDMI Adopter program since 2005, Kordz specialises in providing dependable long-reach HDMI cables, ensuring the seamless transmission of high-quality audio and video signals. Their commitment to excellence is evident in their practical and elegant design, meticulous manufacturing processes, and unwavering support for education initiatives. These factors are crucial in ensuring the successful integration of Kordz products by professional installers.

Kordz offers a comprehensive range of cables, including their renowned Kordz Speaker Cables and Kordz HDMI cables. These cables are trusted by industry professionals for their exceptional performance and reliability, making them the ideal choice for demanding AV installations.

With Kordz, customers can expect nothing short of superior connectivity solutions that enable the flawless transmission of audio and video signals in custom and commercial AV setups. Their dedication to quality, innovation, and installer support sets Kordz apart as a leader in the industry, providing peace of mind and optimal performance for every installation project.



Specification

CONSTRUCTION

  • Conductor: 28AWG solid OFC 0.338 +0/-0.02mm
  • Insulation: Polyethylene, 0.61±0.1 mm
  • Twisting: 4 Twisted pairs of conductors, not bonded
  • Twisted Pair Colour Code: 1: white / blue 2: white-orange / orange 3: white / green 4: white-brown / brown
  • Shielding: Unshielded (U/UTP)
  • Jacket Material: FRLSZH composite
  • Outer Diameter: 4.0 ± 0.5 mm

MECHANICAL

  • Minimum Bend Radius: Without load ≥ 16.0 mm; with load ≥ 32.0 mm
  • Temperature Range: During operation -20 °C to 60°C; During installation 0°C to 50°C

ELECTRICAL

  • DC Resistance: Max. 23.6 Ω/100 m at 20°C
  • Resistance Unbalance: Max. 4% at 20°C
  • Insulation Resistance (500V): Min. 5000 MΩ/km at 20°C
  • Mutual Capacitance: Max. 5.6 nf/100 m at 1 kHz
  • Capacitance Unbalance (Pair to ground): Max. 330 pf/100 m at 1 kHz
  • Nominal Velocity of Propagation: Nom. 67%
  • Test Voltage (DC, 1min): 1 kV / 1 min
  • Cat 6 - 1000Mbps / 1 Gbps (Max Transmission Speed at 100m) - >250 MHz (Max Bandwidth)

DIMENSIONS

  • 330mm x 265mm x 340mm / 13.0in x 10.4in x 13.4in
