Gold Note Tube-1006/1012 Tube Output Stage
£3,800.00 £3,166.67
SKU
Gold Note Tube
Free UK Delivery
12 Months
New
48 Hours
Request Price MatchThe Gold Note TUBE-1006 and TUBE-1012 are high-end valve output stages with 6 and 12 valves, respectively, designed to enhance audio performance by providing warm, natural sound with ultra-low distortion. They feature a Totem-Pole design, dual audio inputs, and are compatible with both Gold Note and other audio systems.
Related Products
promotional_banner_4
promotional_banner_4
Gold Note Tube-1006/1012 Tube Output Stage
The TUBE-1012 and TUBE-1006 models feature class A output stages with either 12 valves or 6 valves, respectively. This design not only enhances the performance of your Gold Note electronics but also provides a level of sound quality that is truly remarkable.
With a proprietary Totem-Pole design that includes six independent audio stages per tube, these output stages promise an ultra-wide bandwidth response and ultra-low distortion. This guarantees a pure audio signal, ensuring that your music sounds exactly as it was intended by the artist.
The Tube Output Stage offers enhanced connectivity options with new audio inputs on the rear panel, allowing simultaneous connection to two sources. This feature provides you the flexibility to enjoy music from Gold Note sources as well as other manufacturers, all easily selectable from the front panel for user convenience.
Features
- Valve Output Stages
- Six independent audio stages per tube; ultra-wide bandwidth; ultra-low distortion.
- Connect to two sources; dedicated Tube input for Gold Note and line input for others.
- High Compatibility
What Gold Note says
TUBE-1012 and TUBE-1006 further improve the performance of Gold Note electronics, reaching a completely new level thanks to the 12-valve (TUBE-1012) or 6-valve (TUBE-1006) class A output stages. Gold Note sources and amplifications guarantee great control and definition while providing exceptional realism in recreating the musical event. But those who love the warm sound of valves and want to bring their system to its maximum performance will find TUBE-1012 or TUBE-1006 the right choice. Working in perfect synergy with Gold Note electronics, you can have a wonderfully natural sound and a High-End listening experience.
The proprietary Totem-Pole design, with six independent audio stages per Tube, ensures an ultra-wide bandwidth response and ultra-low distortion, guaranteeing a pure audio signal. Thanks to the new audio inputs on the rear panel, our valve output stages can be connected simultaneously to two sources: using the Tube input for Gold Note sources and the line input for those from other manufacturers. The input is selectable from the front panel for maximum convenience and ease of use.
Specification
- MAX INPUT (THD < 1%)
- RCA 6Vrms
- XLR 12Vrms
- MAX OUTPUT (THD < 1%)
- RCA 8Vrms
- XLR 16Vrms
- OUTPUT IMPEDANCE: <600Ω
- GAIN: 2dB
- RECOMMENDED LOAD: >10kΩ
- TUBES
- TUBE-1006 – 6 valves 6n1p
- TUBE-1012 – 12 valves 6n1p
- THD+N: 0.0028% @ 1kHz – 1.736V
- S/N: >100dB @ 1kHz – 1.736V
- INPUTS TUBE
- 1x XLR Line In
- 1x RCA Line In
- 1x Tube In (5-pole XLR for Gold Note sources only)
- POWER CONSUMPTION
- TUBE-1012 – 80W
- TUBE-1012 – 80W
- POWER SUPPLY
- 100-120V or 220-240V, 50/60Hz
- Super Linear Vacuum Tube Regulator with 4 Inductive Choke filters
- FUSE (220/240V): 2A F
- FUSE (100/120V): 3,15A F
- DIMENSIONS: 430mm W | 135mm H | 370mm D
- WEIGHT
- TUBE-1012 – Kg. 16 net – Kg. 21 boxed
- TUBE-1006 – Kg. 13,3 net – Kg. 19 boxed
- MODELS
- TUBE-1012
- 12 valves
- Power consumption 80W
- 3x Gold Note custom transformer
- TUBE-1006
- 6 valves
- Power consumption 50W
- 2x Gold Note custom transformer
About Gold Note
Gold Note, the leading Italian manufacturer in the High-End audio industry, was founded in Firenze in 2012 by Maurizio Aterini, who serves as the CEO and driving force behind the brand. With a focus on Italian craftsmanship, Gold Note offers a complete line of digital and analogue equipment catering to audiophiles worldwide.
Gold Note's story combines tradition and innovation, inspired by the rich history, art, and technology of Firenze. The brand values creativity, technical expertise, and a sense of beauty, which are reflected in every product they create.
The mission of Gold Note is to deliver the full experience of music, capturing the emotion of listening. They strive to achieve perfect musicality through innovative technology, exquisite materials, and Italian design. The result is a full-bodied sound with impeccable imaging, dynamics, and precise placement of instruments and voices.
Gold Note's sound is distinctively Italian, characterised by vivid realism, precise imaging, accurate instrument separation, speed, and clarity of detail. They aim to provide a natural and balanced sound that combines analytical and sentimental qualities, resulting in a unique Italian Sound.
The philosophy of Gold Note revolves around systems thinking, emphasising the synergy created by the components and the entire audio chain. They focus on the holistic approach to design, considering the sum of the parts rather than individual constituents. This approach allows them to craft a complete audio chain that delivers true Italian Sound.
As a contemporary High-End audio brand, Gold Note combines innovation and tradition to meet the needs of the modern audiophile. They embrace engineering, functional design, and manufacturing challenges, striving for excellence while representing the essence of "Made in Italy." Gold Note carefully selects suppliers known for their exceptional quality, often located in Tuscany, near their headquarters.
Quality control is of utmost importance to Gold Note. Each product undergoes thorough individual testing, ensuring the highest level of quality. The lean production system is followed, with each product assembled by a single technician.
Gold Note's commitment to delivering the ultimate musical experience and their dedication to craftsmanship has established them as a renowned brand in the High-End audio industry.
Specification
- MAX INPUT (THD < 1%)
- RCA 6Vrms
- XLR 12Vrms
- MAX OUTPUT (THD < 1%)
- RCA 8Vrms
- XLR 16Vrms
- OUTPUT IMPEDANCE: <600Ω
- GAIN: 2dB
- RECOMMENDED LOAD: >10kΩ
- TUBES
- TUBE-1006 – 6 valves 6n1p
- TUBE-1012 – 12 valves 6n1p
- THD+N: 0.0028% @ 1kHz – 1.736V
- S/N: >100dB @ 1kHz – 1.736V
- INPUTS TUBE
- 1x XLR Line In
- 1x RCA Line In
- 1x Tube In (5-pole XLR for Gold Note sources only)
- POWER CONSUMPTION
- TUBE-1012 – 80W
- TUBE-1012 – 80W
- POWER SUPPLY
- 100-120V or 220-240V, 50/60Hz
- Super Linear Vacuum Tube Regulator with 4 Inductive Choke filters
- FUSE (220/240V): 2A F
- FUSE (100/120V): 3,15A F
- DIMENSIONS: 430mm W | 135mm H | 370mm D
- WEIGHT
- TUBE-1012 – Kg. 16 net – Kg. 21 boxed
- TUBE-1006 – Kg. 13,3 net – Kg. 19 boxed
- MODELS
- TUBE-1012
- 12 valves
- Power consumption 80W
- 3x Gold Note custom transformer
- TUBE-1006
- 6 valves
- Power consumption 50W
- 2x Gold Note custom transformer
