Gold Note P-1000 MKII Class A Preamplifier

Gold Note P-1000 MKII Class A Preamplifier

The Gold Note P-1000 MKII Class A Preamplifier is a masterpiece of audio engineering, crafted for those who seek the ultimate in sound quality. This high-end preamplifier features a unique six-stage ultra-balanced design that delivers an exceptionally clean and detailed audio signal, with minimal distortion. Equipped with three independent linear power supplies and an ALPS optical encoder volume control, the P-1000 MKII ensures that every nuance of your music is faithfully reproduced. Its eight stereo inputs—four fully balanced XLR and four RCA—offer incredible flexibility for integrating into any sophisticated audio setup.

Designed with the discerning audiophile in mind, the P-1000 MKII includes advanced features that enhance its versatility and performance. The Mono/Stereo selection, left/right channel swap, and absolute phase shift (0°/180°) provide precise control over your audio experience, allowing for perfect playback of both modern and vintage recordings. Additionally, Gold Note's proprietary Booster technology optimizes speaker performance by amplifying low-frequency energy, making this preamplifier an essential component for those who demand the best from their sound systems.

The P-1000 MKII is not only a technical marvel but also a user-friendly device, featuring a large color display that makes navigating its numerous functions intuitive and straightforward. Whether adjusted via the front panel or remote control, the P-1000 MKII allows for quick and precise fine-tuning to suit your listening preferences. For those who wish to take their audio system to even greater heights, the P-1000 MKII can be paired with optional external units like the TUBE-1012/1006 valve stages or the PSU-1250/1000 power supplies, further enhancing its already remarkable performance.

Features

• Six-Stage Ultra-Balanced Design: Delivers low distortion and superior sound quality
• ALPS Optical Encoder Volume Control: Ensures precise volume adjustments
• Three Independent Linear Power Supplies: Enhances signal stability
• 8 Stereo Inputs: 4 XLR and 4 RCA for versatile connectivity
• Mono/Stereo Selection: Switch between mono and stereo modes
• Left/Right Channel Swap: Corrects inverted recordings
• Absolute Phase Shift (0°/180°): Adjusts audio phase for system integration
• Booster Technology: Amplifies low frequencies for speakers needing extra power

State-of-the-art technology for the Class A preamplifier dedicated to true music lovers

Designed for High-End audio systems, the P-1000 MkII is an innovative Class A preamplifier developed with a new proprietary six-stage ultra-balanced design with relays and ALPS optical encoder volume control.
The P-1000 MkII features a design with three independent linear power supplies and 8 stereo inputs: 4 fully balanced XLR and 4 RCA. It also offers numerous advanced functions: Mono/Stereo selection, left/right channel swap, absolute phase swap, Booster technology and excellent left/right balance.

The Deluxe version of the P-1000 MkII is equipped with noise-cancelling coils and capacitors on the six output stages, derived from military technologies, secured in place with custom copper clips.

To perfectly reproduce even the oldest recordings, the preamplifier can be set in both Mono and Stereo modes. It also allows for playback of inverted recordings. Absolute phase shift (0°/180°) can be useful when integrating the preamplifier into your system.

The Booster technology of the P-1000 MkII allows you to get the best out of speakers that require additional power, increasing the emission of energy in a very specific range of low frequencies.
The function is completely bypassed in OFF mode.

Easy to use thanks to the colour display that clearly and intuitively shows all the functions and allows precise and fast adjustments both through the use of the knob on the front panel and the remote control. To further improve its performance, the P-1000 MkII can be paired with the external super inductive PSU-1250/1000 power supply and the TUBE-1012/1006 valve stage.

The P-1000 MkII can be equipped with dedicated external units to further improve performance: the Tube 1012 and Tube-1006 – Class A valve stages – and the PSU-1250 and PSU-1000 – external power supplies.

Specification

• FREQUENCY RESPONSE: 2Hz – 200kHz @ ± 3dB
• THD (TOTAL HARMONIC DISTORTION): < 0.001% @ 1kHz
• GAIN: +19dB
• SIGNAL TO NOISE RATIO: 110dB
• CHANNEL SEPARATION: > 118dB
• CHANNEL LEFT/RIGHT: Selectable swap
• MONO/STEREO: Yes
• ABSOLUTE PHASE: 0°/180°
• BOOSTER: 3 adjustable levels (by-passable/off)
• VOLUME: 100 steps
• REMOTE CONTROL: Included – IR receiver on front and back
• ANALOGUE INPUTS

  • 4x RCA unbalanced
  • 4x XLR balanced
• INPUT LEVEL

  • RCA – nominal 2Vrms, max up to 5Vrms
  • XLR – nominal 2Vrms, max up to 10Vrms
• INPUT IMPEDANCE: 100kΩ XLR & RCA
• AUDIO OUTPUTS

  • 2x RCA unbalanced
  • 2x XLR balanced
  • 1x TUBE-1012
• OUTPUT LEVEL: Max up to 20Vrms on XLR & 10Vrms on RCA
• OUTPUT IMPEDANCE: < 50Ω XLR & RCA
• POWER SUPPLY: 100-120V or 220-240V, 50/60Hz
• Ultra Linear power supply with 3 transformers
• POWER CONSUMPTION: max 30W
• PSU INPUT: 1 Input for external inductive power supply PSU-1250/1000
• FUSE (220/240V): 1A F
• FUSE (100/120V): 2A F
• DIMENSIONS: 430mm W | 135mm H | 375mm D
• WEIGHT

  • Kg. 11 – net
  • Kg. 16 – boxed
• MODELS
• P-1000 MKII DELUXE
  • Audiophile audio-grade components and military-grade anti-noise coils and capacitors clamped with custom copper clips.
• P-1000 MKII
  • Audiophile audio-grade components.
