CYP SY-XTREAM-C – 4K HDMI to USB-C Capture & Recorder

£374.03 £311.69
SKU
SY-XTREAM-C
Free UK Delivery
5 Years
New
24 hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

The CYP SY-XTREAM-C is a high-quality 4K HDMI to USB-C capture and recorder device that supports resolutions up to 4K UHD+ with HDR, featuring an HDMI bypass function for streaming at 4K@30Hz to USB-connected PCs, and includes integrated audio mixing capabilities. It is compatible with most video capture and streaming software due to its compliance with UAC and UVC standards, offers video timing stabilisation, and can be powered via USB-C, making it a portable and versatile option for content capture and broadcasting.

CYP SY-XTREAM-C – 4K HDMI to USB-C Capture & Recorder



If you are looking for a high-quality and versatile HDMI to USB video capture recorder, then the CYP SY-XTREAM-C is the perfect product for you. With its ability to support resolutions up to 4K UHD+ (18Gbps) with HDR, this capture and recorder device offers superior quality and performance.

One of the most impressive features of the SY-XTREAM-C is its HDMI bypass function, which allows you to stream audio and video signals at up to 4K@30Hz to a USB connected PC for capture or re-broadcast. This means you can easily capture and record your desired content without compromising on the quality.

Moreover, the device also supports a second audio stream which can be captured from various sources such as line input, mic input, or a mixture of both, providing you with multiple options for audio recording. The integrated audio mixer allows you to combine the line and mic inputs, giving you full control over your audio recordings.

In addition, the SY-XTREAM-C is compliant with the UAC and UVC standards, making it compatible with most common video capture, chat, and streaming software. This includes the popular Free OBS software, which is available for Windows PC, macOS, and Linux.

Another standout feature of this product is its video timing stabilisation, which ensures a stable and reliable USB capture stream, even if the HDMI input source is intermittent or disconnected. This is a crucial factor to consider when choosing a video capture device, as it can greatly impact the quality of your recordings.

Furthermore, the SY-XTREAM-C is powered directly by the USB-C connection, eliminating the need for an external power supply. This makes it a convenient and portable option for on-the-go use. However, for non-USB-C computers, the SY-XTREAM-C also offers a separate product, the SY-XTREAM, which requires an external power supply.



Features

  • HDMI input and output supports up to 4K@60Hz with HDR bypass
  • HDCP 2.2 and HDCP 1.x compliant Note: Video capture of sources using HDCP encryption is not supported
  • USB 3.0 connection allows uncompressed video and audio data capture (up to 4K@30Hz, LPCM 2.0) Note: 4K sources with frame rates higher than 30Hz are automatically converted to 4K@30Hz for USB capture
  • 2 additional analog audio inputs via 3.5mm ports (1 x Stereo & 1 x Microphone)
  • Supports capture of stereo audio from the HDMI input (LPCM 2.0) as a part of the primary stream, as well as audio from one or both of the analog audio inputs as a secondary audio stream
  • Integrated audio mixer provides a way to combine the line and mic analog audio inputs
  • Complies with the UAC (USB Audio Class) and UVC (USB Video Class) standards, allowing the unit to support most common capture and video streaming software Note: Access to many of the software controllable features of the unit, beyond simple video capture, requires the use of the USB Video Capture Control software which is only available for Windows 10 or later PCs
  • Supports video timing stabilisation to help ensure a reliable and stable USB capture stream
  • Unit may be powered directly via USB-C connection (USB3.0)
  • Supports the Free OBS (Open Broadcaster Software) streaming software which is available for Windows 10 (or later), macOS, and Linux

SY-XTREAM-CSpecification

Inputs:

  • 1x HDMI [1x HDMI Uncompressed AV and Data]
  • 1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]
  • 1x 3.5mm Stereo mini-jack [1x Microphone]

Outputs:

  • 1x HDMI [1x HDMI (bypass) Uncompressed AV and Data]
  • 1x USB-C [1x USB-C / Thunderbolt]
  • PSU: USB powered
  • Dimensions: 80mm [W] x 1150mm [D] x 250mm [H]
  • Net Weight: 180g
  • Gross Weight: 380g



About CYP

CYP's vision is simple, to deliver market-leading connectivity solutions that enhance the capability of Audio Visual products in any installation environment. Continued dedication and focus has made CYP a market leader in connectivity solutions for both systems integrators and professional AV installers throughout Europe. They have a range of over 350 tried and tested products that offer a standard of performance and reliability that cannot be matched.

The key to building such a successful range lies with the ability to continuously develop new products that drive innovation. Within AV distribution this requires an excellent market understanding and the very best R&D engineers. CYP have a continuous new product roadmap containing over 30 projects at any one time, this ensures that they can always provide their partners with innovative application of the very latest technology.

From their European headquarters in Shepperton (UK), they support distributors, systems integrators and installers throughout Europe, the Middle East and Africa. From initial specification of projects through to industry-leading after-sales support and training, they provide their partners with complete confidence in the AV solutions they deliver. Behind this support is a dedicated team of product managers and engineers who all have the skills and experience to deliver practical help at every stage of the CYP journey. It is this passion for the industry and pride in their products that makes them the perfect manufacturer partner.



Specification

Inputs:

  • 1x HDMI [1x HDMI Uncompressed AV and Data]
  • 1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]
  • 1x 3.5mm Stereo mini-jack [1x Microphone]

Outputs:

  • 1x HDMI [1x HDMI (bypass) Uncompressed AV and Data]
  • 1x USB-C [1x USB-C / Thunderbolt]
  • PSU: USB powered
  • Dimensions: 80mm [W] x 1150mm [D] x 250mm [H]
  • Net Weight: 180g
  • Gross Weight: 380g
