CYP Pure Digital v1.3 HDMI over single CAT6 Extender Kit with Repeater function

£192.00 £160.00
SKU
CYP PU-1107-KIT
Free UK Delivery
5 Years
New
24 hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

The PU-1107-KIT is an uncompressed Pure Digital solution to extend HDMI signals via a Single CAT6 cable. Product Code - PU-1107-KIT

CYP Pure Digital v1.3 HDMI over single CAT6 Extender Kit with Repeater function



CYP has developed a “best of breed”, market leading range of products for distributing and controlling HD content over long distances utilising CAT5e or CAT6 cable. The Puma Range now includes a selection of CAT5e or CAT6 matrix units which are the perfect solution for any commercial or residential installation requiring extended signal runs.

Pure digital v1.3 HDMI over single CAT6 Extender Set with Repeater function The PU-1107-KIT is an uncompressed Pure Digital solution to extend HDMI signals via a Single CAT6 cable. The PU-1107-KIT extender set can be used with the PU-1107EX Repeater to extend the HDMI signal over single CAT6 up to a total of 80m, 40m either side of the repeater.



Features:

  • Product Code - PU-1107-KIT (Transmitter & Receiver)
  • v1.3 HDMI, HDCP 1.1 & DVI 1.0 compliant
  • HDMI over a single CAT6 (pure digital transmission)
  • Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
  • Resolution supported: 480i - 1080p 50/60, 1080p 24, VGA - WUXGA
  • Supports Deep Colour (10 & 12 bit)
  • Supports xvYCC
  • Supports CEC bypass
  • Supports 3D signals
  • 2 Years Warranty



Schematics



Specifications:

  • Inputs Transmitter: 1 x HDMI [HDMI Uncompressed AV and Data] Receiver: 1 x RJ45 [CAT (HDMI) Propriety Data]
  • Outputs Transmitter: 1 x RJ45 [CAT6 Propriety Data] Receiver: 1 x HDMI (HDMI Uncompressed AV and Data)
  • Power Transmitter: 5v/1A. Receiver: 5V/1.2A, DC (US/EU standards, CE/FCC/UL certified)
  • Dimensions Transmitter: 80mm (W) x 102mm (D) x 32mm (H) Receiver: 79mm (W) x 75mm (D) x 30mm (H)
  • Gross Weight Transmitter: 380g. Receiver: 380g



Box Contains:

  • CYP Pure Digital v1.3 HDMI over single CAT6 Extender Set with Repeater function
  • UK Power Supply
  • User's Manual



Specifications:

  • Inputs Transmitter: 1 x HDMI [HDMI Uncompressed AV and Data] Receiver: 1 x RJ45 [CAT (HDMI) Propriety Data]
  • Outputs Transmitter: 1 x RJ45 [CAT6 Propriety Data] Receiver: 1 x HDMI (HDMI Uncompressed AV and Data)
  • Power Transmitter: 5v/1A. Receiver: 5V/1.2A, DC (US/EU standards, CE/FCC/UL certified)
  • Dimensions Transmitter: 80mm (W) x 102mm (D) x 32mm (H) Receiver: 79mm (W) x 75mm (D) x 30mm (H)
  • Gross Weight Transmitter: 380g. Receiver: 380g
