CYP EL-8300VA Advanced 4K HDMI, USB Type C, Display Port, VGA and HDBaseT Presentation Switch

£1,365.95 £1,138.29
SKU
CYP EL-8300VA
Free UK Delivery
5 Years
New
24 hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

CYP's EL-8300VA has HDMI and HDBaseT outputs, switching and scaling across HDMI, USB-C, DisplayPort and VGA inputs, and also comes with a microphone input. The HDBaseT output is capable of delivering 4K/60 alongside audio and ethernet over up to 100m.

CYP EL-8300VA Advanced 4K HDMI, USB Type C, Display Port, VGA and HDBaseT Presentation Switch



CYP's EL-8300VA has HDMI and HDBaseT outputs, switching and scaling across HDMI, USB-C, DisplayPort and VGA inputs, and also comes with a microphone input. The HDBaseT output is capable of delivering 4K/60 alongside audio and ethernet over up to 100m.



What CYP say



The EL-8300VA is an advanced multi-format presentation switch with integrated scaling across the HDMI, USB-C, Displayport and VGA inputs, plus HDMI and HDBaseT outputs. The EL-8300VA features HDBaseT extension for video up to 4K/60 (4:2:0), plus embedded audio, control and Ethernet over distances of up to 100m. The HDMI, USB-C and DisplayPort inputs support video up to 4K/60 (4:4:4, 8-bit) while the VGA input supports resolutions up to WUXGA. The EL-8300VA is HDCP 2.2 compliant and features 4K/60 4:4:4 upscaling and downscaling across all the inputs.

The EL-8300VA includes multiple analogue stereo audio inputs and microphone input, along with amplified and balanced line-level analogue stereo outputs, providing a range of audio routing and mixing functionality. The built-in audio mixer function allows the user to mix audio from any LPCM 2.0 source with the microphone input for presentation or lecture usage. The ability to switch back and forth between mixed and non-mixed audio provides additional flexibility to the presentation experience.

Trigger inputs allow the easy addition of a remote control keypad (CR-TG1), or third party voltage trigger products, which can be installed within a podium or table in a conference room or classroom. This interface enables the user to activate functions with the simple press of a button. Comprehensive control options are provided via the front panel buttons (various button locking features available), On-Screen Display (OSD), WebGUI, IP Telnet, Voltage Trigger, and RS-232.



Features



  • 8x2 Presentation switcher with HDMI, DisplayPort, VGA and USB-C inputs
  • HDMI 2.0, DVI 1.0 and HDCP 2.2 compliant
  • HDBaseT and HDMI mirrored outputs with scaling functionality
  • Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input and output (HDMI)
  • HDBaseT output transmits video and audio over a single Cat.5e/6/7 cable up to 100m/328ft at 1080p and 70m/230ft at 4K; Auto conversion of 6G signals for HDBaseT output compatibility
  • Audio DSP function allows the mixing of audio from different audio input types plus microphone input balancing
  • Built in 2 x 20 watts audio amplifier
  • Trigger Control Keypad (CR-TG1) support for easy single-button control, function activation (Optional)
  • Control is via OSD, RS-232, Telnet, WebGUI and triggers
  • Comprehensive EDID and HDCP management
  • Supports standard PoH from the unit to connected HDBaseT Receivers (compatible Receivers only)
  • USB Type-C port provides up to 60W of power to connected devices



Specification



  • Inputs
    • 1x USB-C [1x USB-C / Thunderbolt]
    • 5x HDMI [5x HDMI Uncompressed AV and Data]
    • 1x Display Port [1x Display Port Uncompressed AV]
    • 1x 15pin Dsub [1x VGA RGBHV]
    • 1x 6.35mm Stereo Jack [1x Microphone]
    • 6x 3.5mm Stereo mini-jack [6x Analogue Stereo(L/R)]
    • 2x Phoenix (2 pin) [2x Contact Closure Relay Outputs]
    • 1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]
    • 1x Phoenix (4 pin) [1x RS-232 local control]
    • 1x Phoenix (4 pin) [1x RS-232 HDBaseT pathway]
  • Outputs
    • 1x HDMI [1x HDMI Uncompressed AV and Data]
    • 1x RJ45 [1x HDBaseT HDMI & Propriety Data]
    • 1x Phoenix (5 pin) [1x Analogue Stereo (Balanced or Unbalanced)]
    • 2x Phoenix (2 pin) [1x Speaker Level Stereo Output]
  • PSU- 24V/6.25A
  • Dimensions- 432mm [W] x 192mm [D] x 49mm [H]
  • Net Weight- 2550g
  • Gross Weight- 369g



About CYP

CYP's vision is simple, to deliver market leading connectivity solutions that enhance the capability of Audio Visual products in any installation environment. Continued dedication and focus has made CYP a market leader in connectivity solutions for both systems integrators and professional AV installers throughout Europe. They have a range of over 350 tried and tested products that offer a standard of performance and reliability that cannot be matched.

The key to building such a successful range lies with the ability to continuously develop new products that drive innovation. Within AV distribution this requires an excellent market understanding and the very best R&D engineers. CYP have a continuous new product roadmap containing over 30 projects at any one time, this ensures that they can always provide their partners with innovative application of the very latest technology.

From their European headquarters in Shepperton (UK), they support distributors, systems integrators and installers throughout Europe, the Middle East and Africa. From initial specification of projects through to industry leading after sales support and training, they provide their partners with complete confidence in the AV solutions they deliver. Behind this support is a dedicated team of product managers and engineers who all have the skills and experience to deliver practical help at every stage of the CYP journey. It is this passion for the industry and pride in their products that makes them the perfect manufacturer partner.
