CYP EL-7400V HDMI / VGA / Display Port Presentation Switcher & Scaler

£1,009.30 £841.08
SKU
CYP EL-7400V
Free UK Delivery
5 Years
New
24 hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

CYP's EL-7400V Presentation Switcher and Scaler is able to switch and scale as many as 5 AV inputs simultaneously over HDBaseT LITE and HDMI ouptuts. The HDBaseT LITE output allows you to send signals up to 60m over a CAT5e/6/7 cable, and supports analogue, digital coaxial and optical audio outputs.

CYP EL-7400V HDMI / VGA / Display Port Presentation Switcher & Scaler with HDMI & HDBaseT™ Outputs



CYP's EL-7400V Presentation Switcher and Scaler is able to switch and scale as many as 5 AV inputs simultaneously over HDBaseT LITE and HDMI ouptuts. The HDBaseT LITE output allows you to send signals up to 60m over a CAT5e/6/7 cable, and supports analogue, digital coaxial and optical audio outputs.



What CYP say



This HDMI/DisplayPort/VGA to HDMI Scaler with HDBaseT LITE Output is designed to switch and scale up to 5 AV inputs to simultaneous HDMI and HDBaseT LITE outputs at resolutions up to 1080p/WUXGA. The HDBaseT LITE output enables the user to send the signals up to 60m over a single CAT5e/6/7 cable and supports PoH (Power over HDBaseT 48v) to provide power to the connected HDBaseT LITE receiver (PUV-1230PL-RX, PUV-1210PL-RX). Additionally, this device offers 3 analogue Line level audio inputs, Optical, Digital Coax and a Line level output.

Beyond video switching and scaling, this unit also supports Optical Audio Return (OAR). This feature enables optical audio sent from a compatible HDBaseT Receiver to this unit for local playback. An integrated audio DSP with gain control for routing audio and controlling background audio levels adds to the versatility of this Presentation Switch.

The system can be controlled and easily configured via WebGUI, IR remote control or RS-232. This device is an ideal solution for presentation facilities within a classroom, conference room or corporate meeting space.



Features



  • Supports HDMI 1.4 (including HDCP) over a single CAT5e/6/7 up to 60m
  • Complies with HDBaseT™- Lite specifications
  • Supports multiple inputs: 2×HDMI, 2×VGA and 1×DisplayPort, 3×Unbalanced Audio, 1xOptical, 1xDigital Coaxial
  • Provides simultaneous HDMI and HDBaseT LITE outputs (Mirrored)
  • Supports HDTV resolutions up to 1080p (VGA to WUXGA)
  • Audio DSP offers auto-mixing and auto-gain control for mixing or reducing background audio
  • Optical Audio return (OAR) Support
  • Supports Internal EDID Management Support
  • Supports pass-through of LPCM 2.0 audio
  • Supports control via WebGUI, IR remote and RS-232
  • Supports IR In and IR Out to receive or transmit IR signal from compatible HDBaseT receiver with bi-directional RS-232 control



Specification



  • Inputs-
    • 2x HDMI [2x HDMI Uncompressed AV and Data]
    • 1x Display Port [1x Display Port Uncompressed AV]
    • 2x 15pin Dsub [2x VGA RGBHV]
    • 3x 3.5mm Stereo mini-jack [3x Analogue Stereo(L/R)]
    • 1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]
    • 1x Phoenix (3 pin) [1x RS-232]
    • 1x RJ45 [1x LAN Serving]
  • Outputs-
    • 1x HDMI [1x HDMI Uncompressed AV and Data]
    • 1x RJ45 [1x HDBaseT HDMI & Propriety Data]
    • 1x Toslink [1x Optical 2 Channel LPCM]
    • 1x RCA [1x Coaxial 2 Channel LPCM]
    • 1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]
  • PSU- 24V/2.7A
  • Dimensions- 133mm [W] x 215mm [D] x 49mm [H]
  • Net Weight- 1073g
  • Gross Weight- 1520g



About CYP

CYP's vision is simple, to deliver market leading connectivity solutions that enhance the capability of Audio Visual products in any installation environment. Continued dedication and focus has made CYP a market leader in connectivity solutions for both systems integrators and professional AV installers throughout Europe. They have a range of over 350 tried and tested products that offer a standard of performance and reliability that cannot be matched.

The key to building such a successful range lies with the ability to continuously develop new products that drive innovation. Within AV distribution this requires an excellent market understanding and the very best R&D engineers. CYP have a continuous new product roadmap containing over 30 projects at any one time, this ensures that they can always provide their partners with innovative application of the very latest technology.

From their European headquarters in Shepperton (UK), they support distributors, systems integrators and installers throughout Europe, the Middle East and Africa. From initial specification of projects through to industry leading after sales support and training, they provide their partners with complete confidence in the AV solutions they deliver. Behind this support is a dedicated team of product managers and engineers who all have the skills and experience to deliver practical help at every stage of the CYP journey. It is this passion for the industry and pride in their products that makes them the perfect manufacturer partner.





  • Inputs-
    • 2x HDMI [2x HDMI Uncompressed AV and Data]
    • 1x Display Port [1x Display Port Uncompressed AV]
    • 2x 15pin Dsub [2x VGA RGBHV]
    • 3x 3.5mm Stereo mini-jack [3x Analogue Stereo(L/R)]
    • 1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]
    • 1x Phoenix (3 pin) [1x RS-232]
    • 1x RJ45 [1x LAN Serving]
  • Outputs-
    • 1x HDMI [1x HDMI Uncompressed AV and Data]
    • 1x RJ45 [1x HDBaseT HDMI & Propriety Data]
    • 1x Toslink [1x Optical 2 Channel LPCM]
    • 1x RCA [1x Coaxial 2 Channel LPCM]
    • 1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]
  • PSU- 24V/2.7A
  • Dimensions- 133mm [W] x 215mm [D] x 49mm [H]
  • Net Weight- 1073g
  • Gross Weight- 1520g
