Blustream PRO16HBT100CS Custom Pro 16x16 HDBaseT CSC Matrix (4K 60Hz 4:4:4 up to 70m)
£12,403.00 £10,335.83
SKU
PRO16HBT100CS
Free UK Delivery
5 Years
New
48 Hours
The pre-configured range of Custom Pro Matrix achieves new levels of both performance and flexibility. The Custom Pro PRO16HBT100CS has been designed to operate in complex and challenging AV environments.
Related Products
promotional_banner_4
promotional_banner_4
Blustream PRO16HBT100CS Custom Pro 16x16 HDBaseT CSC Matrix (4K 60Hz 4:4:4 up to 70m)
The Blustream PRO16HBT100CS Custom Pro 16x16 HDBaseT CSC Matrix is a pre-configured bundle that sets new standards in performance and flexibility. Specifically designed to excel in complex and challenging AV environments, this matrix offers unparalleled capabilities for professional installations.
With 16 video inputs, 16 video outputs, audio breakout, and 2-way IR control, the PRO16HBT100CS empowers your AV setup with cutting-edge features. It supports remarkable 4K UHD video up to 4K 60Hz 4:4:4 (18Gbps) over HDBaseT™, utilizing Colour Space Conversion (CSC) technology. Experience seamless signal transmission at distances of up to 70m for 4K content or extend the range up to 100m at 1080p resolution, ensuring pristine image quality even in expansive setups.
The HDBaseT™ CSC output boards enhance compatibility by automatically downscaling the 4K 60Hz 4:4:4 video input. While HDMI outputs maintain native pass-through, the CSC boards intelligently downscale the signal to 1080p@60Hz or 4K 60Hz 4:2:0, catering to screens that do not support full 4K 60Hz 4:4:4.
For comprehensive audio integration, the matrix features 16 analogue L/R audio inputs that can be embedded into the corresponding HDMI/HDBaseT™ zone outputs. This ensures synchronized audio transmission alongside video content, delivering an immersive AV experience.
With 16 IR outputs, the PRO16HBT100CS enables convenient control of local source equipment, while the 16 IR inputs facilitate the distribution of IR signals to compatible Blustream HDBaseT™ Receivers. For advanced control options, an optional RS-232 control board is available for bi-directional serial control with equipment connected to Blustream HDBaseT™ Receivers (PRO-8RS232 cards sold separately).
The matrix also includes an audio breakout board with line-level volume control, allowing precise adjustment of audio levels for each zone. Configuration and control of the matrix can be easily managed through a web browser interface, front panel controls, RS-232, TCP/IP, and web GUI/App integration, providing versatility and convenience in operation.
Additionally, the PRO16HBT100CS supports Power over Cable (PoC) when used with compatible Blustream HDBaseT™ Receivers, simplifying the installation process and reducing cable clutter. It is compatible with third-party drivers for major commercial and residential control brands, ensuring seamless integration into existing control systems.
Equipped with advanced EDID management and HDCP 2.2 compliance, the Blustream PRO16HBT100CS Custom Pro Matrix guarantees reliable and secure signal transmission. Pair it with Blustream HEX100CS-RX Receivers (sold separately) for optimal performance, or utilize Blustream HEX70CS-RX Receivers for distances not exceeding 40m at 4K or 70m at 1080p (sold separately).
Elevate your AV installations with the Blustream PRO16HBT100CS Custom Pro 16x16 HDBaseT CSC Matrix and experience unparalleled performance, flexibility, and control.
Features
- Pre-configured Custom Pro matrix bundle with 16 x video inputs, 16 x video outputs, Audio breakout, and 2-way IR control
- Supports 4K UHD video up to 4K 60Hz 4:4:4 (18Gbps) over HDBaseT™ using Colour Space Conversion up to 70m at 4K 60Hz 4:4:4, or up to 100m at 1080p
- HDBaseT™ CSC output boards feature independent automatic downscaling of up to 4K 60Hz 4:4:4 video input to the following formats (HDMI outputs are native pass-through): - 1080p@ 60Hz (for screens that do not support 4K), - 4K 60Hz 4:2:0 (for screens that do not support full 4K 60Hz 4:4:4)
- 16 x analogue L/R audio inputs which can be embedded onto corresponding HDMI / HDBaseT™ zone outputs
- Extend 16 x IR outputs for routed control of local source equipment
- 16 x IR inputs for distribution of IR to compatible Blustream HDBaseT™ Receivers
- Optional RS-232 control board for bi-directional serial control with equipment connected to Blustream HDBaseT™ Receivers (PRO-8RS232 cards sold separately)
- Audio breakout board with line-level volume control
- Web browser interface for control and configuration of Matrix
- Control of Matrix via front panel, RS-232, TCP/IP and web GUI / App
- Supports PoC (Power over Cable) when used with compatible Blustream HDBaseT™ Receivers
- 3rd Party drivers available for major commercial & residential control brands
- Advanced EDID management
- HDCP 2.2 compliant
- Used with Blustream HEX100CS-RX Receivers (sold separately)
- Used with Blustream HEX70CS-RX Receivers - if distance at 4K does not exceed 40m, or 70m at 1080p (sold separately)
Specification
- Video Input Connectors: 16 x HDMI Type A, 19-pin, female
- Video Output Connectors: 12 x HDMI Type A, 19-pin, female, 16 x HDBaseT™ RJ45 connector
- Source Audio Output Connectors: 16 x 3.5mm stereo jack (L/R)
- Zone Audio Output Connectors: 16 x 3.5mm stereo jack (L/R), 16 x RCA Coaxial Digital (S/PDIF)
- Audio Input Connectors: 16 x 3.5mm stereo jack (L/R)
- RS-232 serial ports: 1 x 9-pin RS-232 connector
- IR Input ports: 16 x 3.5mm stereo jack
- IR Output ports: 16 x 3.5mm mono jack
- TCP/IP Control: 1 x RJ45 connector, female
- Rack-Mountable: 4U rack height, rack ears included
- Casing Dimensions (W x H x D): 440mm x 173mm x 422m without feet
- Dimensions Including Connections (W x H x D): 440mm x 178mm x 430mm with feet
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature : -4°F to 140°F (-20°C to 60°C)
- Power Supply: Internal 100-240V AC, IEC cable supplied
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
About Blustream
Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.
Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.
Specification
- Video Input Connectors: 16 x HDMI Type A, 19-pin, female
- Video Output Connectors: 12 x HDMI Type A, 19-pin, female, 16 x HDBaseT™ RJ45 connector
- Source Audio Output Connectors: 16 x 3.5mm stereo jack (L/R)
- Zone Audio Output Connectors: 16 x 3.5mm stereo jack (L/R), 16 x RCA Coaxial Digital (S/PDIF)
- Audio Input Connectors: 16 x 3.5mm stereo jack (L/R)
- RS-232 serial ports: 1 x 9-pin RS-232 connector
- IR Input ports: 16 x 3.5mm stereo jack
- IR Output ports: 16 x 3.5mm mono jack
- TCP/IP Control: 1 x RJ45 connector, female
- Rack-Mountable: 4U rack height, rack ears included
- Casing Dimensions (W x H x D): 440mm x 173mm x 422m without feet
- Dimensions Including Connections (W x H x D): 440mm x 178mm x 430mm with feet
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature : -4°F to 140°F (-20°C to 60°C)
- Power Supply: Internal 100-240V AC, IEC cable supplied
