Blustream IP350UHD-RX IP Multicast HDMI 2.0 Video Receiver with Dante
£971.00 £809.17
SKU
IP350UHD-RX
Free UK Delivery
5 Years
New
24 hours
The Blustream IP300 series Multicast distribution platform allows virtually latency free (1 frame) distribution of 4K HDMI video over a 1Gb managed network. Featuring full interoperability with the IP300UHD product line, the IP350UHD-RX is an industry leading Dante enabled 4K HDCP 2.2 HDMI receiver that, using visually lossless compression technology, delivers 18Gbps HDMI, Dante & AES67 audio, bi-directional IR, RS-232 & USB/KVM up to lengths of 100m over standard copper network architecture, or greater distances using the in-built fibre SFP network interface.
promotional_banner_4
promotional_banner_4
Blustream IP350UHD-RX IP Multicast HDMI 2.0 Video Receiver with Dante
The Blustream IP350UHD-RX IP Multicast HDMI 2.0 Video Receiver with Dante has a number of features that make it a great choice for those looking to distribute 4K HDMI video and audio over a network. Firstly, it has virtually no latency (1 frame), making it ideal for live events and gaming applications, where timing is critical.
It also supports full 18Gbps HDMI, Dante, and AES67 audio, as well as bi-directional IR, RS-232, and USB/KVM up to distances of 100m over standard copper network architecture or greater distances using the built-in fibre SFP network interface. This means that it can easily distribute high-quality video and audio signals over long distances without the need for additional cabling.
In addition to its advanced signal management capabilities, the Blustream IP350UHD-RX can support video and Dante audio distribution from a single network, with a second RJ45 connection allows for the Dante audio network interface to be segregated from the video over IP network if required. It also features full 18Gbps HDMI scaling capabilities, allowing for lower resolutions to be used where legacy displays are required in the same system as full 4K.
The flexibility of the Blustream Multicast video over IP solution makes this platform ideal for multiple installation types, including matrix distribution, video walls, one-to-one HDMI extenders, and one-to-many HDMI extenders. The unit can be powered via PoE from the network switch or locally should the switch not support PoE, and also has an optional 24V power supply if needed.
Overall, the Blustream IP350UHD-RX is a powerful and versatile solution for anyone looking to distribute 4K HDMI video and audio over a network, with advanced features and flexible configuration options that make it a great choice for a wide range of applications.
Here is what Blustream say about the IP350UHD-RX
The Blustream IP300 series Multicast distribution platform allows virtually latency free (1 frame) distribution of 4K HDMI video over a 1Gb managed network. Featuring full interoperability with the IP300UHD product line, the IP350UHD-RX is an industry-leading Dante enabled 4K HDCP 2.2 HDMI receiver that, using visually lossless compression technology, delivers 18Gbps HDMI, Dante & AES67 audio, bi-directional IR, RS-232 & USB/KVM up to lengths of 100m over standard copper network architecture, or greater distances using the in-built fibre SFP network interface.
The IP350UHD-RX can support both video and Dante audio distribution from a single network. A second RJ45 connection allows for the Dante audio network interface to be segregated from the video over IP network if required. With a full 18Gbps HDMI scaling chipset on board, the HDMI output can be adjusted to lower resolutions where legacy displays are required in the same system as the full 4K. The scaling capabilities of this unit also allow for videowalls to be created where needed. The unit can be powered via PoE from the network switch or locally should the switch not support PoE. With multiple configuration options available, the flexibility of the Blustream Multicast video over IP solution makes this platform ideal for multiple installation types.
Features
- Advanced 4K HDMI 2.0 video over 1Gb managed network supporting 18Gbps HDMI signals
- Virtually unlimited system size
- Extends HDMI up to a distance of 100m over a single CAT cable
- SFP port for signal distribution over fibre
- Supports up to 4K UHD 60Hz 4:4:4
- Supports HDR including Dolby Vision LLM
- Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
- Extends HDMI and Dante up to a distance of 100m over a single CAT cable
- Dual RJ45 network ports configurable for independent or combined HDMI and Dante signal distribution
- SFP port for independent or combined HDMI and Dante signal distribution over a single fibre cable
- Advanced signal management for independent routing of IR, RS-232, USB/KVM, audio and video
- PoE (Power over Ethernet) to power Blustream unit from PoE switch
- HDCP 2.2 compliant with full 18Gbps scaling capabilities for inclusion of non-4K / legacy displays whilst distributing 4K to other parts of the system
- Analogue L/R audio output supports both balanced and unbalanced audio signals
- Optical (S/PDIF) input for 2ch optical audio return that can be fed into Dante network
- OLED front panel display for advanced system information and manual configuration
- Optional 24V power supply (should Ethernet switch not support PoE)
- Compatible with Blustream IP300UHD-TX and IP350UHD-TX/RX products
- Features 4 operational modes:
- Matrix distribution (requires 1Gb network switch)
- Video wall (requires 1Gb network switch)
- One-to-one HDMI extender (no network switch required)
- One-to-many HDMI extender (no network switch required)
Specification
- Video Input: 1 x LAN RJ45 connector, 1 x SFP connector
- Video Output: 1 x HDMI Type A, female, 1 x LAN RJ45 connector
- Audio Input: 1 x 5-pin Phoenix connector
- Audio Output: 1 x 5-pin Optical (S/PDIF) connector
- Dante Port: 1 x LAN RJ45 connector (LAN2)
- Fibre Port: 1 x SFP connector (fibre module not supplied)
- RS-232 Serial Port: 1 x 3-Pin Phoenix connector
- USB/KVM Port: 1 x USB2.0-type B for KVM
- IR Input: 1 x 3.5mm stereo jack
- IR Output: 1 x 3.5mm mono jack
- Dimensions (W x D x H ): 190mm x 128mm x 25mm
- Packaging Dimensions (W x D x H): 260mm x 180mm x 55m
- Unit Weight: 0.75kg
- Power Consumption: 12W (max)
- Shipping Weight: 1kg
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature : -4°F to 140°F (-20°C to 60°C)
- Power Supply: Class 3 IEEE 802.3af POE PD or 24V 1A DC PSU
Box Contents
- 1 x IP350UHD-RX
- 1 x IRR Receiver
- 1 x IRE1 Emitter
- 1 x Audio 5-pin Phoenix Connector
- 1 x Serial 3-pin Phoenix Connector
- 1 x Mounting Kit
About Blustream
Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.
Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.
Specification
- Video Input: 1 x LAN RJ45 connector, 1 x SFP connector
- Video Output: 1 x HDMI Type A, female, 1 x LAN RJ45 connector
- Audio Input: 1 x 5-pin Phoenix connector
- Audio Output: 1 x 5-pin Optical (S/PDIF) connector
- Dante Port: 1 x LAN RJ45 connector (LAN2)
- Fibre Port: 1 x SFP connector (fibre module not supplied)
- RS-232 Serial Port: 1 x 3-Pin Phoenix connector
- USB/KVM Port: 1 x USB2.0-type B for KVM
- IR Input: 1 x 3.5mm stereo jack
- IR Output: 1 x 3.5mm mono jack
- Dimensions (W x D x H ): 190mm x 128mm x 25mm
- Packaging Dimensions (W x D x H): 260mm x 180mm x 55m
- Unit Weight: 0.75kg
- Power Consumption: 12W (max)
- Shipping Weight: 1kg
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature : -4°F to 140°F (-20°C to 60°C)
- Power Supply: Class 3 IEEE 802.3af POE PD or 24V 1A DC PSU
Box Contents
- 1 x IP350UHD-RX
- 1 x IRR Receiver
- 1 x IRE1 Emitter
- 1 x Audio 5-pin Phoenix Connector
- 1 x Serial 3-pin Phoenix Connector
- 1 x Mounting Kit
