Blustream HMXL88ARC 8x8 HDBaseT™ CSC ARC Matrix - 70m (4K 60Hz 4:4:4 up to 40m)
£3,138.00 £2,615.00
SKU
HMXL88ARC
Free UK Delivery
5 Years
New
24 hours
The HMXL88ARC HDBaseT™ Matrix delivers new levels of advanced audio integration into our Essential range of 4K video matrix solutions. The HMXL88ARC is an 8x8 HDMI 2.0 4K 60Hz 4:4:4 matrix that uses CSC (Colour Space Conversion) technology to deliver 18Gbps HDMI over distances of up to 40m (1080p to 70m).
Related Products
promotional_banner_4
promotional_banner_4
Blustream HMXL88ARC 8x8 HDBaseT™ CSC ARC Matrix - 70m (4K 60Hz 4:4:4 up to 40m)
The Blustream HMXL88ARC 8x8 HDBaseT™ CSC ARC Matrix brings exceptional audio integration to our Essential range of 4K video matrix solutions. Designed with cutting-edge technology, the HMXL88ARC is an 8x8 HDMI 2.0 4K 60Hz 4:4:4 matrix that utilizes Colour Space Conversion (CSC) to transmit 18Gbps HDMI signals over distances of up to 40m (1080p up to 70m).
One of the standout features of the HMXL88ARC is its enhanced audio routing capabilities, made possible by the integrated 26x8 audio matrix. This allows seamless embedding and routing of audio from both displays and sources according to the user's preferences, creating a truly immersive audiovisual experience.
The matrix offers versatile connectivity options with 8 HDMI inputs that can be independently routed to 8 HDBaseT™ outputs. Output 1 even provides simultaneous HDMI and HDBaseT™ output for added flexibility. With video smart scaling on the HDBaseT™ outputs, displays that support lower video resolutions can still receive pristine 4K 60Hz 4:4:4 content while maintaining the original 4K UHD resolution on other video outputs.
Supporting 4K 60Hz 4:4:4 UHD video up to 40m and 1080p video up to 70m, the HMXL88ARC ensures stunning visual quality and optimal signal transmission. The extensive audio matrix offers various audio source inputs, including audio breakout from HDMI source inputs, audio breakout from zone outputs, ARC from zone outputs, as well as optical and analogue audio inputs. It supports popular HDMI audio formats such as Dolby TrueHD, Dolby Atmos, Dolby Digital Plus, and DTS-HD Master Audio, guaranteeing immersive sound reproduction.
Configuration and control of the matrix are made effortless with the built-in web browser interface, allowing seamless integration into your existing setup. The HMXL88ARC also supports bi-directional IR and RS-232 on all HDBaseT™ outputs, ensuring smooth communication and integration with third-party control systems. Control options include front panel, IR, iOS/Android App, RS-232, and TCP/IP.
Furthermore, the matrix supports 24V Power over Cable (PoC) to power compatible Blustream RX70CS receivers, eliminating the need for additional power supplies. It comes with Blustream IR receivers and emitters, offering convenience and ease of use.
Equipped with advanced EDID management and HDCP 2.2 compliance, the HMXL88ARC guarantees seamless and secure transmission of high-quality content.
Discover the power of advanced audio integration and seamless video distribution with the Blustream HMXL88ARC 8x8 HDBaseT™ CSC ARC Matrix. Elevate your audiovisual experience and enjoy unparalleled control and flexibility for your professional installations.
Features
- Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
- Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR*
- Features 8 x HDMI inputs which can be independently routed to 8 x HDBaseT™ outputs
- Output 1 features simultaneous HDMI and HDBaseT™ output
- Video Smart Scaling on HDBaseT™ outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
- Supports 4K 60Hz 4:4:4 UHD video up to 40m and 1080p video up to 70m
- 26x8 Audio Matrix independently controllable from video. Audio source inputs include:
- 8 x audio breakout from HDMI source inputs
- 8 x audio breakout from zone outputs
- 8 x ARC from zone outputs*
- 1 x Optical and 1 x Analogue audio input
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Web interface module for control and configuration of matrix
- Supports bi-directional IR and RS-232 on all HDBaseT™ outputs
- Control via front panel, IR, iOS / Android App, RS-232 and TCP/IP
- Supports 24V PoC (Power over Cable) to power compatible Blustream RX70CS receivers
- Supplied with Blustream IR receivers and emitters
- Advanced EDID management and HDCP 2.2 compliant
*ARC feature supports HDMI ARC or Optical ARC *PoC, CSC, and ARC feature compatible with RX70CS only
Colour Space Conversion (CSC) Technology in HDBaseT™
Due to the data rate of HDBaseT™ technology being capped at 10.2Gbps, it is unable to pass the latest native 4K UHD resolutions of 4K 60Hz 4:4:4. There is now a requirement to integrate video resolutions with data speeds up to 18Gbps across a multi-zone AV environment. Blustream have implemented CSC (Colour Space Conversion) technology into our latest products to ensure 4K HDR signals can now be supported over the limited infrastructure of HDBaseT™. Colour Space Conversion reduces the data rate of the HDMI signal by converting the colour space from 4:4:4 or 4:2:2 to a lower format. Within Colour Space Conversion technology the native resolution and frame rate remain constant from end to end. The only part of the signal that is converted during transmission is the colour. Blustream CSC products do not support HDR10+ or the dynamic variation of Dolby Vision due to the way these specific variations of dynamic HDR (dHDR) are encoded. These codecs transmit repeated metadata packets throughout the transmission of any media making it impossible at this stage to convert in the same way using CSC technology.
Specification
- Video Input Connectors: 8 x HDMI Type A, 19-pin, female
- Video Output Connectors: 1 x HDMI Type A, 19-pin, female, 8 x HDBaseT™ RJ45 connector, used with RX70CS receiver
- Audio Input Connectors: 1 x Analogue audio L/R (3.5mm stereo jack), 1 x Optical (S/PDIF)
- Audio Output Connectors: 8 x Analogue audio L/R (3.5mm stereo jack), 8 x Optical (S/PDIF)
- RS-232 Serial Ports: 9 x 3-pin Phoenix connector
- TCP/IP Control: 1 x RJ45, female
- IR Input Ports: 9 x 3.5mm stereo jack
- IR Output Ports: 9 x 3.5mm mono jack
- Rack Mountable: 2U rack height, rack ears included
- Casing Dimensions (WxDxH): 436mm x 400mm x 88mm (without feet)
- Shipping Weight: 10.5kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
- Power Supply: Internal 100-240V AC
Box Contents
- 1 x HMXL88ARC
- 1 x Rack Mounting Kit
- 1 x Remote Control
- 8 x IR Emitters
- 9 x IR Receivers
- 1 x Serial Cable - DB9 to 3-pin Phoenix Connector
- 1 x IR Control Cable - 3.5mm-3.5mm Cable
- IEC Power Cable(s)
- 1 x Quick Reference Guide
About Blustream
Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.
Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.
Specification
- Video Input Connectors: 8 x HDMI Type A, 19-pin, female
- Video Output Connectors: 1 x HDMI Type A, 19-pin, female, 8 x HDBaseT™ RJ45 connector, used with RX70CS receiver
- Audio Input Connectors: 1 x Analogue audio L/R (3.5mm stereo jack), 1 x Optical (S/PDIF)
- Audio Output Connectors: 8 x Analogue audio L/R (3.5mm stereo jack), 8 x Optical (S/PDIF)
- RS-232 Serial Ports: 9 x 3-pin Phoenix connector
- TCP/IP Control: 1 x RJ45, female
- IR Input Ports: 9 x 3.5mm stereo jack
- IR Output Ports: 9 x 3.5mm mono jack
- Rack Mountable: 2U rack height, rack ears included
- Casing Dimensions (WxDxH): 436mm x 400mm x 88mm (without feet)
- Shipping Weight: 10.5kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
- Power Supply: Internal 100-240V AC
Box Contents
- 1 x HMXL88ARC
- 1 x Rack Mounting Kit
- 1 x Remote Control
- 8 x IR Emitters
- 9 x IR Receivers
- 1 x Serial Cable - DB9 to 3-pin Phoenix Connector
- 1 x IR Control Cable - 3.5mm-3.5mm Cable
- IEC Power Cable(s)
- 1 x Quick Reference Guide
