Blustream HEX100CS-KIT HDBaseT™ CSC Extender Set Supporting HDMI2.0 4K60Hz 4:4:4 up to 70m (1080p up to 100m)

£584.00 £486.67
SKU
HEX100CS-KIT
Free UK Delivery
5 Years
New
24 hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

Blustream's HEX100CS-KIT HDMI2.0 4K60Hz 4:4:4 (18Gbps) HDCP2.2 HDBaseT™ extender set offers market leading features and outstanding value utilising CSC technology.
promotional_banner_4
promotional_banner_4

Blustream HEX100CS-KIT HDBaseT™ CSC Extender Set Supporting HDMI2.0 4K60Hz 4:4:4 up to 70m (1080p up to 100m)



Blustream's HEX100CS-KIT HDBaseT™ CSC Extender Set is a market-leading solution for extending HDMI signals up to 100m (4K up to 70m) over a single CAT cable. With advanced HDBaseT™ technology, this extender set offers the distribution of video and audio with outstanding value utilising CSC technology. The set includes both a transmitter and receiver unit, each equipped with a range of features to ensure reliable signal transmission.

The HEX100CS-KIT supports HDMI2.0 18Gbps specification, including HDR, with advanced colour space conversion (CSC) technology. This means it supports 4K 60Hz 4:4:4 UHD video up to 70m and extends HDMI 1080p video up to 100m. Additionally, the transmitter includes an HDMI loop-out for integrating local displays or cascading to multiple devices.

This extender set supports all industry standard video resolutions, including VGA-WUXGA and 480i-4K, and all known digital HDMI audio formats, including Dolby TrueHD, Atmos, DTS-HD Master Audio, and DTS:X transmissions. The HDBaseT™ Receiver also includes HDMI re-clocking, which helps to solve HDMI HDCP, compatibility, and handshaking issues.

The HEX100CS-KIT also includes HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently, bi-directional RS-232 pass-through, bi-directional IR pass-through, and advanced EDID management. The set is HDCP2.2 compliant and comes supplied with a Blustream 5V IR receiver and emitter.

Overall, the Blustream HEX100CS-KIT HDBaseT™ CSC Extender Set is an ideal solution for anyone looking to extend their HDMI signals with the latest technology and a range of advanced features.





Features

  • Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
  • Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
  • Supports 4K 60Hz 4:4:4 UHD video up to 70m
  • Extends HDMI 1080p video up to 100m
  • Features 1x HDMI loop-out on HEX100CS-TX for integrating local displays or cascading to multiple devices
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • HDMI re-clocking on the HDBaseT™ Receiver to help solve HDMI HDCP, compatibility and handshaking issues
  • HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
  • Supports bi-directional RS-232 pass through
  • Supports bi-directional IR pass through
  • Supplied with Blustream 5V IR receiver and emitter
  • Advanced EDID management
  • HDCP2.2 compliant



Specification

  • HEX100CS-TX transmitter
    • Video Input Connectors: 1x HDMI Type A, female
    • Video Output Connectors: 1x HDBaseT™ RJ45 connector, 1x HDMI Type A, female
    • RS-232 serial port: 1x DB-9 female
    • IR Input ports: 1x 3.5mm stereo jack
    • IR Output ports: 1x 3.5mm mono jack
    • EDID DIP switch: 4-pin
  • HEX100CS-RX receiver
    • Video Input Connectors: 1x HDBaseT™ RJ45 connector
    • Video Output Connectors: 1x HDMI Type A, female
    • RS-232 serial port: 1x DB-9 female
    • IR Input ports: 1x 3.5mm stereo jack
    • IR Output ports: 1x 3.5mm mono jack
    • Audio Output Connectors: 1x RCA (SPDIF) & 2x Analogue RCA (Left/Right)
  • Power Supply: 12V / 2A DC, screw type connector
  • Power Consumption: 12.7W
  • Transmitter Dimensions (WxDxH): 143 x 134 x 22mm (without connections)
  • Transmitter Dimensions (WxDxH): 143 x 141 x 22mm (with connections)
  • Receiver Dimensions (WxDxH): 113 x 124 x 22mm (without connections)
  • Receiver Dimensions (WxDxH): 113 x 138 x 22mm (with connections)
  • Ind. Extender Weight: 0.35kg (excluding accessories)
  • Carton / Box Dimensions (WxDxH): TBC
  • Shipping Weight: 1.4kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
  • Mounting kits included

Contents

  • 1x HEX100CS-TX
  • 1x HEX100CS-RX
  • 2x Mounting brackets
  • 1x 12V / 2A power supply
  • 1x IR emitter
  • 1x IR receiver
  • 1x Quick Reference Guide



Blustream 4K60Hz 4:4:4 Feature Icon Blustream HDBaseT Feature Icon Blustream HD Audio Feature Icon
Blustream 3D Feature Icon Blustream EDID Feature Icon Blustream PoE Feature Icon
Blustream CSC Feature Icon Blustream HDCP2.2 Feature Icon



About Blustream

Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.

Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.



Specification

  • HEX100CS-TX transmitter
    • Video Input Connectors: 1x HDMI Type A, female
    • Video Output Connectors: 1x HDBaseT™ RJ45 connector, 1x HDMI Type A, female
    • RS-232 serial port: 1x DB-9 female
    • IR Input ports: 1x 3.5mm stereo jack
    • IR Output ports: 1x 3.5mm mono jack
    • EDID DIP switch: 4-pin
  • HEX100CS-RX receiver
    • Video Input Connectors: 1x HDBaseT™ RJ45 connector
    • Video Output Connectors: 1x HDMI Type A, female
    • RS-232 serial port: 1x DB-9 female
    • IR Input ports: 1x 3.5mm stereo jack
    • IR Output ports: 1x 3.5mm mono jack
    • Audio Output Connectors: 1x RCA (SPDIF) & 2x Analogue RCA (Left/Right)
  • Power Supply: 12V / 2A DC, screw type connector
  • Power Consumption: 12.7W
  • Transmitter Dimensions (WxDxH): 143 x 134 x 22mm (without connections)
  • Transmitter Dimensions (WxDxH): 143 x 141 x 22mm (with connections)
  • Receiver Dimensions (WxDxH): 113 x 124 x 22mm (without connections)
  • Receiver Dimensions (WxDxH): 113 x 138 x 22mm (with connections)
  • Ind. Extender Weight: 0.35kg (excluding accessories)
  • Carton / Box Dimensions (WxDxH): TBC
  • Shipping Weight: 1.4kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
  • Mounting kits included
  • Contents

    • 1x HEX100CS-TX
    • 1x HEX100CS-RX
    • 2x Mounting brackets
    • 1x 12V / 2A power supply
    • 1x IR emitter
    • 1x IR receiver
    • 1x Quick Reference Guide
