Blustream HD12DB-V2 7.1ch Dolby® / DTS Down Mixing DAC 2-Way HDMI Splitter & Scaler 4K 60Hz 4:4:4

£450.00 £375.00
SKU
HD12DB-V2
Free UK Delivery
5 Years
New
Pre-Order
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

Please note: The first shipment of the HD12DC-V2 is due early July 2024.

The Blustream HD12DB-V2 is a 4K 60Hz 4:4:4 HDMI splitter and scaler with an in-built DAC that downmixes 7.1ch Dolby and DTS audio to 2ch stereo, supporting advanced audio formats like Dolby Atmos and DTS. It features one HDMI input, two HDMI outputs, HDCP 2.2 compliance, and advanced EDID management, ensuring high-quality video and audio distribution with versatile connectivity options.

promotional_banner_4
promotional_banner_4

Blustream HD12DB-V2 7.1ch Dolby® / DTS Down Mixing DAC 2-Way HDMI Splitter & Scaler 4K 60Hz 4:4:4



Please note: The first shipment of the HD12DC-V2 is due early July 2024



The Blustream HD12DB-V2 is the perfect solution for anyone looking to distribute 4K UHD video and multi-channel audio throughout their home without compromising on audio quality. With its advanced features and capabilities, this device stands out as a top choice for any home entertainment system.

One of the standout features of the HD12DB-V2 is its ability to downmix embedded 7.1ch Dolby Audio or DTS Audio into a stereo 2ch signal. This means that you can enjoy crystal clear audio, even in rooms that do not support multi-channel audio. With the in-built DAC, you can easily convert the audio to a format that is supported by your equipment.

The device also supports multi-channel audio input formats up to Dolby Atmos and DTS:X, ensuring that you have access to the latest and most advanced audio technologies. This is perfect for avid movie lovers and audiophiles who want to experience the best sound quality possible.

In addition, the HD12DB-V2 features 1 HDMI input and 2 HDMI outputs, providing the option to replicate the HDMI input signal to multiple devices. The HDMI loop out also allows for the replication of 4K 60Hz 4:4:4 video and 7.1ch Dolby Audio & DTS Audio, making it a breeze to distribute high-quality content to multiple rooms.

Furthermore, the device includes an HDMI audio breakout that allows for concurrent downmixing of analogue L/R audio and downmixed optical digital outputs. This means that you can connect the HD12DB-V2 to a variety of audio equipment without any compatibility issues.

Last but not least, the HD12DB-V2 is HDCP 2.2 compliant and offers advanced EDID management. This ensures that your content is protected and properly managed, providing peace of mind and a hassle-free experience.



Features:

  • Features an in-built DAC (Digital to Analogue audio converter) that converts 7.1ch Dolby Audio or DTS Audio to a stereo 2ch signal available on HDMI, optical and analogue audio outputs concurrently
  • Supports multi channel audio input formats up to Dolby Atmos and DTS:X
  • Features 1 x HDMI input supporting 4K UHD video (4K 60Hz 4:4:4) that is replicated to 2x HDMI outputs
  • HDMI loop out will replicate the HDMI input signal up to 4K 60Hz 4:4:4 and 7.1ch Dolby Audio & DTS Audio
  • HDMI output 2 features a video downconversion from 4K down to 1080p
  • HDMI audio breakout to downmixed analogue L/R audio and downmixed optical digital outputs concurrently
  • HDCP 2.2 compliant with advanced EDID management



Specification

  • Dimensions (W x H x D): 195mm x 21mm x 93mm
  • Shipping Weight: 1.0 Kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: - 4°F to 140°F (- 20°C to 60°C)
  • Power Supply: 12V/1A DC
  • Video Input Connectors: 1 x HDMI Type A, 19-pin, female
  • Video Output Connectors: 2 x HDMI Type A, 19-pin, female
  • Audio Output Connectors: 1 x Optical (Toslink), 2 x RCA analogue left / right, 1 x 5-Pin Phoenix balanced/unbalanced left/right
  • EDID Selection: 4-Pin DIP Switch
  • Output 2 Scaler Selection / Optical Output Selection: 4-Pin DIP Switch
  • Product upgrade: 1 x Micro USB female



Box Contents

  • 1 x HD12DB-V2
  • 1 x 12V / 1A DC Power Supply
  • 1 x Mounting Kit
  • 4 x Rubber Feet
  • 1 x Quick Reference Guide



About Blustream

Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.

Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.



Specification

  • Dimensions (W x H x D): 195mm x 21mm x 93mm
  • Shipping Weight: 1.0 Kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: - 4°F to 140°F (- 20°C to 60°C)
  • Power Supply: 12V/1A DC
  • Video Input Connectors: 1 x HDMI Type A, 19-pin, female
  • Video Output Connectors: 2 x HDMI Type A, 19-pin, female
  • Audio Output Connectors: 1 x Optical (Toslink), 2 x RCA analogue left / right, 1 x 5-Pin Phoenix balanced/unbalanced left/right
  • EDID Selection: 4-Pin DIP Switch
  • Output 2 Scaler Selection / Optical Output Selection: 4-Pin DIP Switch
  • Product upgrade: 1 x Micro USB female
