Blustream CUSTOMPRO-HUB16 Custom Pro Matrix Hub w/ 16x Modular Bays
£4,053.00 £3,377.50
SKU
CUSTOMPRO-HUB16
Free UK Delivery
5 Years
New
Special Order
The Custom Pro Matrix achieves new levels of both performance and flexibility. The Custom Pro Hub16 features 12 x modular bays allowing AV integrators to easily specify their desired I/O structure and choose the additional control features required for a specific project. The Custom Pro Matrix has been specifically designed to operate in challenging AV environments. Its robust housing and interlocking board configuration make both installation and maintenance a seamless experience.
Related Products
promotional_banner_4
promotional_banner_4
Blustream CUSTOMPRO-HUB16 Custom Pro Matrix Hub w/ 16x Modular Bays
Please Note: The CUSTOMPRO-HUB16 has IR Control cards included as standard.
Introducing the Blustream CUSTOMPRO-HUB16 Custom Pro Matrix Hub, the perfect solution for AV integrators looking for performance and flexibility in their I/O structure. This advanced matrix hub features 16 modular bays, allowing for easy customization of the input, output, and control features to meet the specific needs of your project.
Designed to operate in challenging AV environments, the Custom Pro Matrix Hub is housed in a robust and interlocking board configuration, making both installation and maintenance a seamless experience. It comes equipped with IR control cards included as standard, giving you complete control of your local source equipment.
The Custom Pro Matrix Hub supports up to 16 video inputs and 16 video outputs using a combination of 2-way and 4-way interchangeable input and output boards. It also supports 4K UHD video up to 4K 60Hz 4:4:4, and optional Colour Space Conversion (CSC) boards support HDMI 2.0 18Gbps specification, including HDR over HDBaseT™.
Advanced optional features of the Custom Pro Matrix Hub include independent down-scaling of 4K video inputs on CSC HDBaseT™ outputs, allowing displays only capable of supporting lower video resolutions to receive 4K video while still showing a native 4K UHD resolution on the higher-definition displays. Other features include audio breakout with variable line-level outputs, simultaneous HDBaseT™ / HDMI outputs, and RS-232 pass-through.
In addition, the Custom Pro Matrix Hub features a 2-way IR pass-through and a web browser interface module for control and configuration of the matrix. The 16 analogue L/R audio inputs can be embedded into corresponding HDMI / HDBaseT™ zone outputs, and the 16 IR outputs allow for routed control of local source equipment. The matrix also supports PoC (Power over Cable) when used with compatible Blustream HDBaseT™ Receivers.
Control of the Custom Pro Matrix Hub is available via front panel, RS-232, TCP/IP, IR, and web GUI. It also supports HDCP 2.2 compliance and advanced EDID management. With 3rd party drivers available for major control brands, the Custom Pro Matrix Hub is a versatile solution for any AV integration project.
Please note that full 4K 60Hz 4:4:4 support is subject to input/output boards specified. Overall, the Blustream CUSTOMPRO-HUB16 Custom Pro Matrix Hub is an advanced, flexible solution that performs better in challenging AV environments.
Features
- Custom Pro Matrix with 12 x modular bays for population of input / output / control boards
- Supports up to 16x video inputs and 16x video outputs using a combination of 2-way and 4-way interchangeable input and output boards
- Supports 4K UHD video up to 4K 60Hz 4:4:4*
- Optional Colour Space Conversion (CSC) boards support HDMI 2.0 18Gbps specification including HDR over HDBaseT™
- Optional CSC boards feature independent downscaling of up to 4K 60Hz 4:4:4 video input to the following formats: - 1080p @ 60Hz (for screens that do not support 4K), - 4K 60Hz 4:2:0 (for screens that do not support full 18Gbps 4K 60Hz 4:4:4)
- 16 x analogue L/R audio inputs which can be embedded onto corresponding HDMI / HDBaseT™ zone outputs
- 16 x IR outputs for routed control of local source equipment
- 16 x IR inputs for distribution of IR to compatible Blustream HDBaseT™ Receivers
- Optional RS-232 control board for bi-directional IR control with Blustream HDBaseT™ Receivers
- Optional Analogue and Digital Audio breakout board with line-level volume control
- Web browser interface for control and configuration of Matrix
- Control of Matrix via front panel, RS-232, TCP/IP, IR and web GUI
- Supports PoC (Power over Cable) when used with compatible Blustream HDBaseT™ Receivers
- 3rd Party drivers available for major control brands
- Advanced EDID management
- HDCP 2.2 compliant
- * full 4K 60Hz 4:4:4 support is subject to input/output boards specified
PRO-IN2HAB
The PRO-IN2H2V input board offers 2x HDMI and 2x VGA sources that can be independently routed to any HDMI/HDBaseT™ output board and features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-IN4HAB
The PRO-IN4HAB board features 4x HDMI 2.0 inputs supporting 4K 60Hz 4:4:4 that can be independently routed to any HDMI/HDBaseT™ output board. Each HDMI input includes an independent fixed level 2ch analogue audio breakout and features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-IN2H2V
The PRO-IN2H2V input board offers 2x HDMI and 2x VGA sources that can be independently routed to any HDMI/HDBaseT output board and features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT4HTCS
The PRO-OUT4HTCS output board offers 4x dual HDBaseT™ outputs for connection to a HDBaseT™ receiver and HDMI display per zone. The PRO-OUT4HTCS utilises CSC technology allowing support of HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 100m (4K to 70m). The PRO-OUT4HTCS also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT4TCS
The PRO-OUT4TCS output board offers 4x independent HDBaseT™ outputs utilising CSC technology allowing support of HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 100m (4K to 70m). The PRO-OUT4TCS also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT2TCS
The PRO-OUT2TCS output board offers 2x independent HDBaseT™ outputs utilising CSC technology allowing support of HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 100m (4K to 70m). The PRO-OUT2TCS also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT4TL-V2
The PRO-OUT4TL-V2 output board offers 4x independent HDBaseT™ outputs utilising CSC technology allowing support of HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 70m (4K to 40m). The PRO-OUT4TL-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT2TL-V2
The PRO-OUT2TL-V2 output board offers 2x independent HDBaseT™ outputs utilising CSC technology allowing support of HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 70m (4K to 40m). The PRO-OUT2TL-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT4TLS-V2
The PRO-OUT4TLS-V2 output board offers 4x dual HDBaseT™ outputs for connection to a HDBaseT™ receiver and HDMI display per zone. The PRO-OUT4TLS-V2 utilises CSC technology allowing support of HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 70m (4K to 40m). The PRO-OUT4TLS-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT4H-V2
The PRO-OUT4H-V2 supports HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) with HDCP 2.2, allowing distribution of inputs to four independent displays. The PRO-OUT4H-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-OUT2H-V2
The PRO-OUT2H-V2 supports HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) with HDCP 2.2, allowing distribution of inputs to two independent displays. The PRO-OUT2H-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-8IR
The PRO-8IR IR routing board offers 8x IR outputs for routed control of local source hardware and 8x IR inputs for distribution of IR to compatible HDBaseT™ receivers. The PRO-8IR also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-8RS323
The PRO-8RS232 RS-232 routing board offers 8x bi-directional RS-232 ports for serial communication from all input and output locations when used with compatible Blustream HDBaseT™ transmitters & receivers. The PRO-8RS232 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
PRO-8ABV
The PRO-8ABV audio breakout board offers 8x simultaneous coaxial digital and variable line-level analogue L/R audio outputs and features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
Specification
- Audio Input Connectors: 16 x 3.5mm stereo jack (L/R)
- RS-232 serial ports: 1 x 9-pin RS-232 connector
- IR Input ports: 16 x 3.5mm stereo jack
- IR Output ports: 16 x 3.5mm mono jack
- TCP/IP Control: 1 x RJ45, female
- Rack-Mountable: 4U rack height, rack ears included
- Casing Dimensions (W x H x D): 440mm x 173mm x 422m without feet
- Dimensions Including Connections (W x H x D): 440mm x 178mm x 430mm with feet
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Power Supply: Internal 100-240v AC
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
About Blustream
Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.
Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.
.
Specification
- Audio Input Connectors: 16 x 3.5mm stereo jack (L/R)
- RS-232 serial ports: 1 x 9-pin RS-232 connector
- IR Input ports: 16 x 3.5mm stereo jack
- IR Output ports: 16 x 3.5mm mono jack
- TCP/IP Control: 1 x RJ45, female
- Rack-Mountable: 4U rack height, rack ears included
- Casing Dimensions (W x H x D): 440mm x 173mm x 422m without feet
- Dimensions Including Connections (W x H x D): 440mm x 178mm x 430mm with feet
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Power Supply: Internal 100-240v AC
