Blustream C88CS Contractor 8x8 HDBaseT™ CSC Matrix - 70m (4K up to 40m)
£2,299.00 £1,915.83
SKU
C88CS
Free UK Delivery
5 Years
New
24 hours
Blustream's Contractor 8x8 HDBaseT™ Matrix offers unprecedented performance and value for the custom installation market. The C88CS is a HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 Matrix utilising CSC technology* to deliver HDMI, Bi-directional IR and PoC up to lengths of 40m over a single CAT cable (1080p to 70m).
Related Products
promotional_banner_4
promotional_banner_4
Blustream C88CS Contractor 8x8 HDBaseT™ CSC Matrix - 70m (4K up to 40m)
The Blustream's Contractor 8x8 HDBaseT™ Matrix is a cutting-edge solution that combines exceptional performance and unbeatable value for the custom installation market. The C88CS Matrix is an HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 Matrix that leverages CSC technology* to deliver top-notch features such as HDMI, bi-directional IR, and PoC transmission over distances of up to 40m with 1080p extending up to 70m over a single CAT cable.
With the C88CS Matrix, you can experience the ultimate versatility and control. This Matrix supports advanced HDBaseT™ technology, enabling video and audio distribution over a single CAT cable. Thanks to the advanced Colour Space Conversion (CSC), it effortlessly handles HDMI 2.0 18Gbps specifications, including HDR, for unparalleled visual fidelity.
Equipped with eight HDMI inputs that can be independently routed to eight HDBaseT™ outputs, the C88CS Matrix offers unparalleled flexibility. Output 1 even supports simultaneous HDMI and HDBaseT™ output, allowing for seamless integration into various setups. The Matrix's HDBaseT™ outputs feature video down-conversion, enabling displays with limited resolution capabilities (such as 4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while preserving the original 4K UHD resolution on other video outputs.
Experience the full potential of your audiovisual content with the C88CS Matrix. It supports 4K 60Hz 4:4:4 UHD video up to 40m, while extending HDMI 1080p video up to an impressive 70m. Whether you're dealing with industry-standard video resolutions like VGA-WUXGA or pushing the boundaries with 480i-4K, this Matrix has you covered. It also ensures compatibility with all known HDMI audio formats, including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus, and DTS-HD Master Audio transmission.
Take control of your matrix setup effortlessly using the web interface module, which provides a user-friendly platform for configuration and control. The C88CS Matrix offers multiple control options, including front panel, IR, RS-232, and TCP/IP, ensuring seamless integration into any system. You can power compatible HDBaseT™ receivers using the convenient PoC (Power over Cable) feature, with the RX70CS receiver being the recommended choice for 18Gbps CSC support.
Blustream doesn't stop at exceptional functionality. The C88CS Matrix comes complete with Blustream IR receivers and emitters, ensuring hassle-free installation and operation. Additionally, third-party drivers are available for major control brands, allowing for easy integration into existing control systems. With its sleek 1U design for 19" rack mount integration and the included mounting kit, this Matrix is perfect for professional installations. Enjoy advanced EDID management and rest assured, knowing that the C88CS Matrix is HDCP 2.2 compliant, ensuring seamless content protection.
Unlock the full potential of your audiovisual setup with the Contractor 8x8 HDBaseT™ CSC Matrix. Blustream delivers superior performance and unbeatable value in one powerful package.
Features
- Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
- Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
- Features 8 x HDMI inputs which can be independently routed to 8 x HDBaseT™ outputs
- Output 1 features simultaneous HDMI and HDBaseT™ output
- Video down-conversion on HDBaseT™ outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
- Supports 4K 60Hz 4:4:4 UHD video up to 40m
- Extends HDMI 1080p video up to 70m
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Web interface module for control and configuration of matrix
- Supports bi-directional IR on all HDBaseT™ outputs
- Control via front panel, IR, RS-232 and TCP/IP
- Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers (RX70CS recommended)
- Supplied with Blustream IR receivers and emitters
- 3rd party drivers available for major control brands
- 1U Design for 19" rack mount integration - mounting kit included
- Advanced EDID management
- HDCP 2.2 compliant
- Recommended receiver: RX70CS (where 18Gbps CSC support is required)
Specification
- Video Input Connectors: 8 x HDMI Type A, 19-pin, female
- Video Output Connectors: 1 x HDMI Type A, 19-pin, female, 8 x HDBaseT™ RJ45 connector
- RS-232 Serial Port: 1 x DB9 Serial connector
- TCP/IP Control: 1 x RJ45, female
- IR Input Ports: 9 x 3.5mm stereo jack
- IR Output Ports: 8 x 3.5mm mono jack
- Rack Mountable: 1U rack height, rack ears included
- Case Dimensions (without feet & connections) (W x D x H): 437mm x 377mm x 44mm
- Case Dimensions (with feet & connections) (W x D x H): 437mm x 384mm x 53mm
- Shipping Weight: 6.25kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
- Power Supply: Internal 100-240V AC
Contents
- 1 x C88CS
- 1 x Rack Mounting Kit
- 1 x Remote Control
- 8 x IR Emitters
- 9 x IR Receivers
- 1 x RS-232 Control Cable
- 1 x IR Control Cable - 3.5mm-3.5mm Cable
- 1 x Quick Reference Guide
- Power Cable(s)
 |
 |
 |
 |
 |
 |
 |
 |
About Blustream
Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.
Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.
Features
- Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
- Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
- Features 8 x HDMI inputs which can be independently routed to 8 x HDBaseT™ outputs
- Output 1 features simultaneous HDMI and HDBaseT™ output
- Video down-conversion on HDBaseT™ outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
- Supports 4K 60Hz 4:4:4 UHD video up to 40m
- Extends HDMI 1080p video up to 70m
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Web interface module for control and configuration of matrix
- Supports bi-directional IR on all HDBaseT™ outputs
- Control via front panel, IR, RS-232 and TCP/IP
- Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers (RX70CS recommended)
- Supplied with Blustream IR receivers and emitters
- 3rd party drivers available for major control brands
- 1U Design for 19" rack mount integration - mounting kit included
- Advanced EDID management
- HDCP 2.2 compliant
- Recommended receiver: RX70CS (where 18Gbps CSC support is required)
Specification
- Video Input Connectors: 8 x HDMI Type A, 19-pin, female
- Video Output Connectors: 1 x HDMI Type A, 19-pin, female, 8 x HDBaseT™ RJ45 connector
- RS-232 Serial Port: 1 x DB9 Serial connector
- TCP/IP Control: 1 x RJ45, female
- IR Input Ports: 9 x 3.5mm stereo jack
- IR Output Ports: 8 x 3.5mm mono jack
- Rack Mountable: 1U rack height, rack ears included
- Case Dimensions (without feet & connections) (W x D x H): 437mm x 377mm x 44mm
- Case Dimensions (with feet & connections) (W x D x H): 437mm x 384mm x 53mm
- Shipping Weight: 6.25kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
- Power Supply: Internal 100-240V AC
Contents
- 1 x C88CS
- 1 x Rack Mounting Kit
- 1 x Remote Control
- 8 x IR Emitters
- 9 x IR Receivers
- 1 x RS-232 Control Cable
- 1 x IR Control Cable - 3.5mm-3.5mm Cable
- 1 x Quick Reference Guide
- Power Cable(s)
